Passive Infrared & Microwave
Installation method: Hanging
Installation height: 1.8-3m
Detecting method: Doppler floating(MW) PIR
Detecting speed: 0.2-7m/s
Tamper switch: NC.25mA/30VDC
Alarm outp |
|
|
|
|
|
|
|
|
PIR detector,12 meter
Working Voltage:9-16VDC
Working Current:15mA,12vDC
Contact of Alarm:NC,12VDC,100mA max
Contact of Tamper:NC,12VDC,100mA max
Time to Alarm:2.2s
Time to Warm-up:2 minu |
|
|
|
|
|
|
|
|
Passive Infrared & Microwave
Detecting speed: 0.2m/s-3.5m/s
Self-adaption of frequency tracing
Supply current: 9-15V/ DC 30mA
Temp&humidity: -30?-70? 5%-95% (RH)
PIR zones: 9+5=14
|
|
|
|
|
|
|
|
|
PIR detector,10meter
Working Voltage:9-16VDC
Working Current:12mA
Contact of Alarm:NC,12VDC,100mA max
Contact of Tamper:NC,12VDC,100mA max
Time to Alarm:2.2s
Time to Warm-up:2 minutes |
|
|
|
|
|
|
|
|
Passive Infrared & Microwave
Detection distance: 18m*18m
Installation way: Wall-hanging
Detecting speed: 0.2m/s-3.5m/s
Operation voltage: 8.2-16VDC
Flexibility: Grade 2, adjustable
Anti-EMI: 500 |
|
|
|
|
|
|
|
|
Dual Technology Motion(Infrared and Microwave)Detector,25M
Operating Voltage:9-16VDC
Current:25mA
Contacts of Alarm:NC,12VDC,50mA max
Contacts of Tamper:NC,12VDC,100mA max
Time to Alarm:2.2s
Time to Warm-up:2 minutes
|
|
|
|
|
|
|
|
|
|
DDT118 Dual Technology Motion Detectors has Intelligent Control, Microprocessor, Top View and Elegant Design which are Suitable For Luxurious Residence and Commercial Environment, especially for Parti |
|
|
|
|
|
|
|
|
Dual Technology with Shelter Immunity,15M
Operating Voltage:9-16VDC
Current:25mA
Contacts of Alarm:NC,12VDC,50mA max
Contacts of Tamper:NC,12VDC,100mA max
Time to Alarm:2.2s
Time to Warm-up:2 minutes |
|
|
|
|
|
|
|
|
PIR & MW Intruder Detector
Model DT-7425
Sensor Dual PIR+MW
Detection distance 3~6m,5~9m,6~12m,9~15m to be selected
Power input 9~16VDC
Current consumption ≈35mA @ 12VDC (standby:25 mA,Alar |
|
|
|
|
|
|
|
|
Passive Infrared & Microwave
Installation method: Top absorption style
Tamper switch: NC.100mA/30VDC Alarm output: NC100mA/30VDC
Anti EMI: > 30v/m 10MHz---1000MHz
Anti-light interference: >8000LUX |
|
|
|
|
|
|
|
|
Passive Infrared & Microwave
Dual element
9 ~ 16 VDC, 12V typical
N.C:15 mA, N.O:5mA 12VDC
N.C/N.O 30VDC, 0.2A max.
1.5 ~ 2.5 sec.
2 / 3 selectable
N.C cover open activates
Red, ca |
|
|
|
|
|
|
|
|
Passive Infrared & Microwave
Detecting method: Doppler floating(MW) PIR
Detecting speed: 0.2-7m/s
Tamper switch: NC.25mA/30VDC
Alarm output: NC50mA/30VDC
Anti EMI: >50v/m 10MHz-1000MHz
Wire: 14- |
|
|
|
|
|
|
